The 60GHz Non-contact Respiratory Sleep Monitoring Radar Sensor is designed for smart elderly care, home healthcare and bedroom monitoring applications. Based on 60GHz mmWave radar technology, it enables non-contact monitoring of human presence, in-bed or out-of-bed status, breathing, heart rate, sleep status and body motion without using cameras or wearable devices.

Product Overview

This radar sensor supports respiratory sleep monitoring, presence detection and sleep-related status detection in a specific area. It is suitable for bedrooms, elderly care rooms, assisted living spaces, smart home projects, hotels and similar indoor environments. With Wi-Fi communication and Tuya Smart compatibility, it can support smart home linkage and convenient app-based monitoring.

Key Features

• Non-contact breathing, heart rate and sleep monitoring

• Human presence detection and no-one detection

• In-bed and out-of-bed status detection

• Body motion monitoring and motion value reporting

• Sleep report, sleep score and sleep status monitoring

• Abnormal struggle state detection

• 60GHz mmWave technology, no camera, better privacy protection

• Wi-Fi communication and Tuya Smart app support

• 5V / 1A USB power supply, wall-mounted installation

Main Functions

Presence Detection: The radar can detect whether someone is present in the monitoring area and report active or no-one status.

In-bed / Out-of-bed Detection: The sensor can identify whether a person is in bed or has left the bed, making it suitable for nighttime elderly care monitoring.

Respiratory & Heart Rate Monitoring: When the user is in bed, the radar can output breathing and heart rate related data for sleep monitoring applications.

Sleep Status Monitoring: The radar can monitor sleep-related status, including awake, light sleep and deep sleep, and generate sleep-related records and reports.

Body Motion Monitoring: The radar can detect motion amplitude and distinguish between static, micro-motion and larger body movement states.

Abnormal State Detection: It can identify abnormal struggle status and support additional smart care reminders through the app or linked smart home system.

Technical Parameters

Recommended Installation

For sleep monitoring applications, the radar is recommended to be installed at an angle of about 45° above the bed head, with an installation height of 0.8m to 1.2m above the bed surface.

• Presence detection range: up to 2m

• In-bed detection range: up to 1m

• Respiratory detection range: up to 1.5m

• Off-bed / unoccupied detection range: up to 2.7m

Application Scenarios

• Bedroom sleep monitoring

• Home healthcare and elderly care

• Nursing home and assisted living projects

• Smart home integration projects

• Hotel and other indoor occupancy monitoring scenarios

Why Choose mmWave Radar?

• No camera design for better privacy

• Not easily affected by light, sunshine or haze

• Real-time sensing of both active and stationary users

• Low-power technology suitable for daily indoor use

Important Notes

• For respiratory sleep detection, it is recommended that only one person is within the detection range.

• Please avoid metal obstruction directly in front of the radar.

• The radar should be installed in a fixed and stable position to avoid vibration-related false alarms.

• The product needs stable power-on time before normal monitoring operation.

If you need quotation, sample support or OEM/ODM cooperation for this product, please contact Kaihe Smart for further assistance.
